High quality Sowing Machine Granular Fertilizer Spreader is offered by China manufacturer Shuoxin. Buy Sowing Machine Granular Fertilizer Spreader which is of high quality directly with low price. This is a brand new fertilizer spreader! Suitable for all kinds of granular fertilizer, can spread grass seeds! Rice! Cold areas can be sprinkled with salt deicing! The whole material box is made of high-quality stainless steel 201 material! Fertilizer tray, fan blade protector are made of stainless steel! Anti-oxidation, anti-fertilizer corrosion! High work efficiency, can work more than 300 acres per day!Suitable for all types of tractors.
1. This machine adopts three-point suspension type and can be used with tractors with rear transmission power output device of 80-120 horsepower or above.
1. Install the fertilizer tank on the machine base and secure it with bolts.
2. Install the fertilizer dialer on the gearbox shaft in the fertilizer box and fix it with bolts.
3. Connect the pull cord to the pull valve, connect the other end of the pull cord to the fertilizer adjustment piece and fix it, and fix the control valve inside the cab for easy operation.
4. To change the fertilization direction on the left side, simply open the pull valve on the left. Applying fertilizer to the right side and vice versa will do this. All that's needed to spread fertilizer completely is to use the draw valves on either side.
5. How to install the driving shaft: Fit the drive shaft's one end onto the fertilizer spreader's gearbox and secure it with a pin. After that, lock the drive shaft in place by installing its other end on the tractor's rear power output shaft.
1. Every time the transmission shaft works, the cross connecting shaft must be lubricated once.
2. Add lubricating oil to the gearbox regularly.
3. Check whether the bolts in various parts are loose every day during use.
4. After use, rinse the machine clean and fill it with lubricating oil to prevent rot.
1200kgFertilizer spreader (double disc) |
|
Dimensions |
1.92*1.36*1.28 |
Weight |
284.5kg |
Capacity |
1200kg |
Fertilizer spreading range |
15-18 meters |
Supporting power |
80-120 HP |
Transfer method |
Power take-off transmission |
Work efficiency |
60 acres/hour |
