Agricultural Hydraulic Flip Plough
  • Agricultural Hydraulic Flip Plough Agricultural Hydraulic Flip Plough
  • Agricultural Hydraulic Flip Plough Agricultural Hydraulic Flip Plough
  • Agricultural Hydraulic Flip Plough Agricultural Hydraulic Flip Plough
  • Agricultural Hydraulic Flip Plough Agricultural Hydraulic Flip Plough
  • Agricultural Hydraulic Flip Plough Agricultural Hydraulic Flip Plough

Agricultural Hydraulic Flip Plough

​Agricultural Hydraulic Flip Plough is an important agricultural machinery equipment that is efficient, labor-saving, and easy to operate. It can not only greatly improve the efficiency and benefits of farming, but also greatly alleviate the labor intensity of farmers.

Send Inquiry

Product Description

 The hydraulic flip plow has a wide range of applications and is very suitable for agricultural production and urban greening needs in various regions.


The Agricultural Hydraulic Flip Plough produced and operated by Shuoxin Machinery has a compact structure, small volume, and easy operation. The hydraulic flipping plow is easy to use, and even without much professional knowledge, workers can master its operating skills. The hydraulic flipping plow has a long service life, which can exceed 10 years, providing strong support for the economic growth of farmers. Hydraulic flipping plows are favored by a large number of users.


Agricultural Hydraulic Flip Plough is easy to operate and cost-effective. The hydraulic flipping plow is very convenient to use, and users can easily adjust it to achieve different tillage depths and angles for different soil conditions. The cost of hydraulic flipping plow is not high, and its cost-effectiveness is also relatively high, making it a reliable choice for farmers. Not only is the cultivation effect amazing, but it can also save a lot of time and energy during the process of plowing.



The Agricultural Hydraulic Flip Plough adopts a combination type, with a three-point suspension connection method. It uses hydraulic flipping and is used in conjunction with a tractor. The lifting and flipping of the plow are controlled by a dual distributor, with reasonable power utilization and strong soil crushing ability, saving time and effort. Multiple specifications, strict production, stable performance, excellent quality, service-oriented, widely used. Hydraulic flipping plows come in various specifications and have a wide range of uses. The hydraulic flipping plow has a wide range of adaptability for cultivation, suitable for areas with black clay, sandy loam, and sandy gravel soil, such as dry fields, paddy fields, greenhouses, orchards, mountainous areas, hills, farms, pastures, etc.


BASIC PARAMETERS

Tractor power HP 200-220
Plow weight 1.5-1.6T
Working width of each ditch 30 cm
Distance between shells 80cm
Mid axis height above ground 170 cm
Tire size 23*9-10
Model 630/530/430/330


Instructions for using Agricultural Hydraulic Flip Plough:

1. Installation: Before using the hydraulic flipping plow, it is necessary to install it properly and adjust parameters such as depth and speed.

2. Debugging: After installation, conduct trial plowing and debug according to the results of the trial plowing to ensure the best use of the hydraulic flipping plow.

3. Usage: When in use, simply control the operating lever through the hydraulic system to easily control parameters such as depth and speed.


Choosing a Agricultural Hydraulic Flip Plough that suits you is very important. When you need to plow or loosen soil in the field, a hydraulic flip plow is an essential equipment that directly affects your agricultural production efficiency and final income. If you need it, please choose our Shuoxin Machinery. Our company has many different models of Agricultural Hydraulic Flip Ploughs to choose from, to ensure that you choose the hydraulic flip plow that suits you and meets your needs. We will wholeheartedly provide you with the highest quality products and services.


In the modernization of agriculture today, Agricultural Hydraulic Flip Plough is a very important agricultural machinery equipment, which injects strong power into the development of modern agricultural economy. As a company with many years of industry experience, Shuoxin Machinery has always been committed to providing customers with better products and services. Shuoxin Machinery Manufacturing Co., Ltd. is an enterprise with its own factory and an excellent reputation in the industry. It is an important leader in the agricultural machinery manufacturing industry. Our factory is located in Pangkou Industrial Zone, Baoding City, Hebei Province, China, close to Tianjin Port, with unique transportation advantages. Our factory has advanced equipment and adopts the latest automated production lines to ensure efficient and high-quality production.

Model

Main frame size

Power(hp)

Working width mm

plowshare

1LF-340

100*100

90-120

3*400

Split plow tip

1LF-360

100*140

120-150

3*600

LEMKEN style plow share

LFT-360 Adjustable

120*120

120-150



LEMKEN style plow share,Double-nut ball screw

1LF-440

100*140

120-150

4*400

Split plow tip

1LFT-440
Adjustable

120*120

120-150



Double-nut ball screw

1LF-450

140*140

160-200

4*500

LEMKEN style plow share

1LFT-450
Adjustable

120*120,140*140

160-200



LEMKEN style plow share,Double-nut ball screw

1LF-550

140*140

220-250

5*500

LEMKEN style plow share

1LFT-550
Adjustable

140*140

220-250



LEMKEN style plow share,Double-nut ball screw


Our Agricultural Hydraulic Flip Plough is designed with a focus on user experience, featuring simple, convenient, efficient, stable, durable, wear-resistant, flexible, effective coverage, and wear resistance. Our company can provide you with the highest quality hydraulic flipping plow. We adopt the most advanced technology to provide customers with excellent service and support.


Hebei Shuoxin Machinery Manufacturing Co., Ltd. is a specialized, refined, innovative and new small and medium-sized enterprise in Hebei Province. The company has strong strength and an important position in performance, which has a profound impact on the agricultural machinery industry. Quality first and service foremost are the principles of Shuoxin Machinery. Customer first, quality first, reputation first, providing customers with high-quality products and services with excellent technology! Welcome to consult and negotiate business at any time!



Hot Tags: Agricultural Hydraulic Flip Plough, China, Manufacturer, Supplier, Factory, Wholesale, Brands, Made in China, Quality, Cheap, Durable
